    GC™32TSi™ Crimper

    A versatile smart crimper, Gates® GC32 TSi™ Crimper offers rock-solid, leak-free, factory-quality hose assemblies every time. With the on-board eCrimp™ you'll always have access to the latest crimp specifications continually updated via WiFi.

    • Intuitive icon-based navigation controls the crimper using a touch-screen tablet control panel.
    • Crimps up to 2" 6 Wire and 2 1/2" industrial hoses.
    • Pinch decompression measurement feature assures crimp OD is within tolerance.

    Intuitive Smart Crimping.

    Our advanced hydraulic hose crimper is designed exclusively to assemble Gates products using an intuitive touch-screen control panel that continually accesses updated Gates eCrimp specifications. The touch screen tablet is removable which allows for live feedback and visual diagnostics. Additionally, this provides a more convenient way to get machine updates in environments that don’t have constant access to Wi-Fi. The GC32 TSi was thoughtfully designed to simplify the user experience with features such as the horizontal load and rear mounted mirror for safe and effective crimping. Likewise, the self-greasing head and build-up reducing valving keeps the crimper going with less maintenance.

    Features and Benefits

    • On-board Gates eCrimp™ specifications continually updated via Wi-Fi.
    • Reduced maintenance with a self-lubricating crimper head using high-compression grease.
    • Standard quick change tool for simple die loading.
    • Horizontal front-end feed makes crimping easier and convenient.
    • 410 ton force that allows crimping of a wide variety of couplings.
    • Full range die sets that enable product of a wide range of hoses.
    • Improved assembly speed with a pre-filled valve for fast attack.
    • Magnetic charge port for constant tablet power while docked.
    • Electrical: 220v - Single Phase; NEMA L6-20 connector.
    • Rated Working Pressure (Max): 4,800 psi (330 bar).
    • Dimensions: 27" x 20" x 30".
